| 型号规格 | 处理风量m3/h | 阻力kg/m2 | 效率% | 外型尺寸（长×宽×高）mm | 重量kg | |||
| X | Y | X | Y | X | Y | |||
| XLP/A-3.0 | 750-1060 |
45-90
|
39-79
|
85-99
|
406×390×6125 | 460×390×1380 | 57 | 43 |
| XLP/A-4.2 | 1460-2060 | 556×545×2177 | 556×545×1880 | 99 | 80 | |||
| XLP/A-5.2 | 2280-3230 | 711×700×2701 | 771×700×2701 | 165 | 128 | |||
| XLP/A-7.0 | 4020-5700 | 911×910×3489 | 911×910×3040 | 265 | 213 | |||
| XLP/A-8.2 | 5500-7790 | 1071×1605×4050 | 1071×1605×3540 | 364 | 293 | |||
| XLP/A-9.4 | 7520-10650 | 1226×1222×4616 | 1226×1222×4050 | 473 | 384 | |||
| XLP/A-10.6 | 9520-13500 | 1376×1337×5157 | 1376×1337×4545 | 631 | 483 | |||
